Description
Hybrid Core Design
Performance-cores provide the speed to handle high-end games and demanding applications while low-priority and background tasks such as streaming video, playing music, and encoding media are handled by the processor’s Efficient-cores.
Intel Thread Director
The Intel Thread Director is built into the CPU’s cores, working with the operating system to ensure each of the 28 threads are assigned to the right core at the right time.
PCIe 4.0 & 5.0
This processor supports up to four PCIe 4.0 and sixteen PCIe 5.0 lanes, delivering 20 lanes in total for exceptional data throughput with compatible devices.
Gaussian & Neural Accelerator 3.0
Gaussian and Neural Accelerator 3.0 (GNA) technology helps with noise suppression while enhancing background blurring during video chats.
Intel Deep Learning Boost
Accelerates AI inference to improve performance for deep learning workloads.
~section~
| Model |
i7-14700F
|
| Total Core(s) | 20 |
| Performance Core(s) | 8 |
| Efficient Core(s) | 12 |
| Thread(s) | 28 |
| Base Frequency |
1.5 GHz
|
| Max Turbo Frequency |
5.4 GHz
|
| Max Memory Bandwidth |
89.6 GB/s
|
| Cache |
33 MB Intel® Smart Cache
|
| Total L2 Cache |
28 MB
|
| Lithography | Intel 7 |
| TDP | Processor Base Power : 65 W Maximum Turbo Power : 219 W |
| Max Memory Size | 192 GB |
| Memory support | Up to DDR5 5600MHz Up to DDR4 3200MHz |
| Memory channel | 2 |
| Max PCI Express Lanes |
20
|
| PCIe Express Version | PCIe 5.0 PCIe 4.0 |
| Max Operating Temperature | 100°C |
| Socket | LGA1700 |
| Instruction Set Extension |
Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2
|
| Launch Date | 01/2024 |
| Product Family | Intel Core i7 Processors 14th Gen Series |
| Warranty | 3 Years Brand Warranty |
