Description
Professional‑Grade Performance – 24 cores and 48 threads built on AMD’s Zen 3 “Chagall PRO” architecture for demanding workstation workloads
High Clock Speeds – 3.8 GHz base frequency with up to 4.5 GHz max boost for both single‑thread and multi‑thread tasks
Massive Cache – 128 MB L3 cache plus 12 MB L2 for faster data access and reduced latency in complex applications
Enterprise Memory Support – 8‑channel DDR4 ECC RDIMM/LRDIMM up to 3200 MHz for stability and data integrity
Unmatched Expandability – 128 PCIe 4.0 lanes for multiple GPUs, NVMe storage arrays, and high‑bandwidth peripherals
Tray Version for System Builders – Ideal for OEMs and custom workstation builds, compatible with sWRX8 socket and WRX80 platform
Please note that a thermal solution is NOT included. A separately purchased dedicated graphics card is required. This processor is backed by a 3-year warranty.
| Model | Threadripper Pro 5965WX |
| Architecture | Zen 3 Core |
| Core(s) | 24 |
| Thread(s) | 48 |
| Base Clock | 3.8 GHz |
| Max. Boost Clock | Up to 4.5 GHz |
| Cache | L1 – 1.5 MB L2 – 12 MB L3 – 128 MB |
| Default TDP | 280W |
| CPU Socket | sWRX8 |
| Socket Count | 1P |
| Processor Technology for CPU Cores | TSMC 7nm FinFET |
| Max. Operating Temperature | 95°C |
| Unlocked for Overclocking | Yes |
| OS Support | Windows 11 – 64-Bit Edition Windows 10 – 64-Bit Edition |
| PCI Express Version | PCIe 4.0 |
| System Memory Type | DDR4 |
| Memory Channels | 8 |
| System Memory Specification | Up to 3200MHz |
| Supported Technologies | AMD “Zen 3” Core Architecture |
| Warranty | 3 Years of Brand Warranty |
